Lumens VC-TA50 AI Auto-Tracking PTZ Camera
Lumens VC-TA50 AI Auto-Tracking PTZ Camera

HD PTZ Camera with Multiple Tracking Modes, 20x Zoom and PoE+

  • AI-Powered Human Face Recognition
  • Three Tracking modes with auto framing
  • 1080P 60fps with 20x Optical Zoom
  • HDMI, SDI, and Ethernet simultaneous output
  • Supports RTSP / RTMP / RTMPS / SRT
  • 5-Year Warranty
  • Features
  • Specifications
  • Brochure

Everywhere Tracking Mode

The camera will follow wherever the presenter goes. You can simply change the tracked subject by clicking on the individual via the web interface.

Partition Tracking Mode

When the presenter moves inside a user-defined Partition Area, the camera switches to a preset angle and zoom. When outside a Partition Area, the camera autonomously follows the presenter.

Stage Tracking Mode

When inside the Tracking Area, the camera follows the presenter with only a pan (left-right) movement. When the presenter moves outside the Tracking Area, the camera stops following.

Smooth Pan-Tilt-Zoom Movement

Whether in auto-tracking or manual mode, VC-TA50 offers a smooth pan, tilt, and zoom movements. The speed of camera movement can be set to meet the needs of each production.

Smart AF

The Smart AF feature keeps the presenter’s face in sharp focus even when they move across a stage. This advanced feature delivers fast, reliable, and accurate focusing performance.

SPECS DETAILS

Sensor

1/2.8" 2.16 MP CMOS

Video Format

1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25
1080i : 60 / 59.94 / 50
720p : 60 / 59.94 / 50

Video Output (HD) Interface

3G-SDI / HDMI / Ethernet

Optical Zoom

20x

Viewing Angle

57° (H) / 32.1° (V) / 65.4° (D)

Aperture

F1.6~F3.8

Focal Length

5.33mm~110mm

Shutter Speed

1/1 ~ 1/10,000 sec

Minimum Object Distance

1.5m (Wide/Tele)

Video S/N Ratio

> 50dB

Minimum Illumination

1.0 lux (F1.6, 50IRE, 30fps)

Focus System

Auto / Manual / Smart AF

Gain Control

Auto / Manual

White Balance

Auto / Manual

Exposure Control

Auto / Manual

WDR

Yes

3D NR

Yes

Image Flip

Yes

AR/VR Systems

FreeD

Tally Light

Yes

Auto-Tracking

Everywhere / Stage / Partition

Auto Framing

Yes

Panning Angle

+170 ~ -170°

Panning Speed

300°/sec

Tilting Angle

+90 ~ -30°

Tilting Speed

300°/sec

Preset Positions

128

HDMI / 3G-SDI

1080p60

IP Stream

First : H.264 1080p 60fps
Second : H.264/MJPEG D1 30fps

IP Compression

H.264 / MJPEG

IP Protocol

RTSP / RTMP / RTMPS / MPEG-TS / SRT

PoE

PoE+ (IEEE802.3at)

Audio Input

Line In / MIC In

Audio Output

Ethernet / SDI / HDMI

Audio Compression Format

G.711

Interface

RS-232 / RS-422 / Ethernet

Protocol

VISCA / VISCAIP / PELCO D / ONVIF

IR Pass-Through

Yes

IR Receiver

Yes

IR Remote Control

Yes

DC In

12V +/- 20%

Power Consumption

PoE : 18.5W
DC In : 17W

Body Color

Black / White

Weight

4.4 lbs (2 kg)

Dimensions

6.9" x 7.3" x 7.3"
(174 x 186 x 187mm )
